ZEFFLE SE Series
ZEFFLE SE is a water-based fluoropolymer emulsion for ultra-weatherproof coatings developed to meet or exceed the performance of its solvent-based counterparts.
ZEFFLE SE based coatings provide reducing the odor and VOC emission during on-site applications, and also fire and health hazards with factory applications.
GRADES & FEATURES
| GRADES | DOWNLOADS | Applications | ||
|---|---|---|---|---|
| Field applications | Coilcoat |
Concrete |
||
| SE-300A | TECHNICAL DATA SHEET | ● | ||
| SE-405 | TECHNICAL DATA SHEET | ● | ● | |
| SE-600 | TECHNICAL DATA SHEET | ● | ● | |
| SE-700 | TECHNICAL DATA SHEET | ● | ||
| FEATURES |
SE-300A |
SE-405 | SE-600 | SE-700 | |
|---|---|---|---|---|---|
|
F content (mass%) |
42 |
36 |
24 |
20 | |
| OHV (mg KOH/g) |
0 |
0 |
0 |
0 | |
| AcidV (mg KOH/g) | 2-3 |
3-4 |
13-14 |
9-10 | |
| Specific gravity (20℃/liquid) | 1.22 | 1.18 | 1.07 | 1.13 | |
|
Specific gravity (20℃/solid) (Calculated value) |
1.44 | 1.36 | 1.18 | 1.26 | |
| Ionic character | Anion / Non-inon | ||||
| Minimum film forming temp. (℃) | 43 | 14 | 26 | 33 | |
|
Particle Diameter (Dynamic light scattering) (nm) |
150-180 | 160-190 | 160-190 | 190-220 | |
| Tg (℃) | 38 | 18 | 25 | 33 | |
| Gloss (60°/white) | 60-65 | 65-70 |
70-75 |
75-80 | |
|
Pencil Hardness (white) |
2B | <6B | --- | 2B | |
| Film strength (MPa) | --- | 5 | N/A | 15 | |
| Film elasitcity (%) | --- | 287 | N/A | 137 | |
|
Chemical resistance * |
Acid 10% H2SO4 |
A | --- | --- | A |
|
Alkali |
A | A | --- | A | |
| Solvent resistance * |
Xylene 100 times |
A | --- | --- | --- |
|
Ethanol 100 times |
A | --- | --- | A | |
| Removability of permanent marker * | Red | A | B | --- | --- |
| Blue | A | B | --- | --- | |
| Black | A | B | --- | --- | |
| Recommendable coalescent | Diethyl adipate |
● |
● | ● | ● |
| Texanol | ● | ● | ● | ||
*: A:excellent / B:fair / C:poor
All values are representative and not guaranteed.
